OULU EV510A-0022G-T2 Three Phase VFD Frequency Drive 10A 2.2kW

The OULU EV510A-0022G-T2 is a robust Three Phase VFD Frequency Drive engineered for demanding industrial applications, delivering precise motor control and enhanced energy efficiency. This 10A, 2.2kW (3HP) unit stands out with its advanced sensorless vector control, ensuring high starting torque and accurate speed regulation even under fluctuating loads. Its compact design facilitates easy integration into control panels, while its comprehensive protection features safeguard connected equipment and prolong operational life. The drive's superior thermal management system, featuring a high-quality heatsink and intelligent fan control, guarantees reliable performance in elevated ambient temperatures. With a wide input voltage range and multiple programmable I/O options, the OULU EV510A-0022G-T2 offers exceptional versatility for a broad spectrum of automation tasks.

Product Specifications

| Feature                  | Specification                               |

| :----------------------- | :------------------------------------------ |

| Model Number             | EV510A-0022G-T2                             |

| Phase                    | Three Phase                                 |

| Rated Current (Output)   | 10A                                         |

| Rated Power (Output)     | 2.2kW (3HP)                                 |

| Input Voltage Range      | 380V-440V (AC)                              |

| Output Frequency Range   | 0-400Hz                                     |

| Control Method           | Sensorless Vector Control, V/f Control      |

| Overload Capacity        | 150% for 60s, 180% for 10s                    |

| Protection Functions     | Over-voltage, Under-voltage, Over-current, Overload, Over-temperature, Phase Loss, etc. |

| Dimensions (H x W x D)   | [Data not readily available in search results] |

| Mounting Type            | DIN Rail or Wall Mount                      |

Core Features & Market Positioning

The OULU EV510A-0022G-T2 distinguishes itself through its advanced sensorless vector control algorithm, providing dynamic torque response and precise speed accuracy comparable to closed-loop systems, a significant advantage in applications requiring consistent performance. Its robust build quality and comprehensive suite of protection mechanisms, including over-voltage, over-current, and over-temperature safeguards, position it as a reliable and durable solution for harsh industrial environments. The drive's ability to operate efficiently across a wide input voltage range (380-440V) enhances its applicability in regions with variable power grids. Furthermore, its user-friendly interface and intuitive parameter settings streamline setup and operation, appealing to both experienced engineers and those new to VFD technology.

Key Application Scenarios

This three-phase VFD is exceptionally well-suited for a variety of industrial applications where precise motor control and energy savings are paramount. It excels in pump and fan control systems, optimizing flow rates and reducing energy consumption by adjusting motor speed according to demand, thereby minimizing wear and tear on machinery. The OULU EV510A-0022G-T2 is also a prime choice for conveyor systems, extruders, and machine tools, where accurate speed regulation and high starting torque are critical for smooth operation and precise material handling or processing. Its versatility extends to HVAC systems, compressors, and general industrial machinery requiring variable speed operation.

Practical System Integration Guidance

Integrating the OULU EV510A-0022G-T2 into an existing industrial setup involves careful consideration of wiring and parameter configuration. Ensure the input power supply is within the specified 380-440V range and is properly protected with appropriate circuit breakers or fuses. Connect the three-phase motor to the drive's output terminals (U, V, W), adhering to correct phasing. Utilize the programmable digital and analog I/O terminals for external control signals, such as start/stop commands, speed references, and feedback signals.

Commissioning typically begins with basic parameter setup, including motor data auto-tuning, which optimizes the drive's performance for the specific motor connected. Essential parameters to configure include the maximum output frequency, acceleration/deceleration times, and motor overload settings to match the motor's nameplate data and application requirements. For enhanced control, explore advanced settings like the sensorless vector control mode if high starting torque or precise speed holding is necessary.

Safety during installation and operation is critical. Always disconnect power before making any wiring changes and ensure the drive is properly grounded. Implement appropriate emergency stop functionality within the control system. Regularly check for parameter misconfigurations that could lead to motor damage or unsafe operation, consulting the user manual for detailed troubleshooting steps for specific error codes.

Operation and Risk Mitigation

Operating the OULU EV510A-0022G-T2 effectively hinges on understanding its control modes and protection features. The sensorless vector control offers superior dynamic performance, while the V/f control provides a simpler yet highly effective solution for basic speed regulation. Users should familiarize themselves with the drive's diagnostic screen to monitor real-time operational data, including current, voltage, frequency, and temperature, which aids in proactive maintenance and performance optimization.

To mitigate operational risks, it is imperative to adhere strictly to the installation guidelines, particularly regarding power supply connections and motor wiring to prevent phase imbalances or short circuits. Overload protection should be configured accurately based on the connected motor's capabilities to prevent premature tripping or damage. Unexpected shutdowns or erratic behavior often stem from incorrect parameter settings or environmental factors; consulting the fault code list provided in the manual is the first step in diagnosing and resolving such issues.

Common fault codes, such as over-current (OC), over-voltage (OV), and under-voltage (UV), typically indicate issues with the motor load, power supply stability, or installation. For instance, an OC fault might suggest the motor is overloaded or the acceleration time is set too short. Addressing these requires a systematic approach: verify motor load, check power supply quality, and review drive parameters to ensure they align with application demands and motor specifications.

Scalability & Long-Term Value

The OULU EV510A-0022G-T2 is designed with scalability in mind, allowing for integration into more complex automation systems. Its programmable I/O capabilities enable it to communicate with PLCs, HMIs, and other control devices, facilitating sophisticated process automation and centralized system management. For applications requiring advanced communication protocols, checking for optional communication cards that support protocols like Modbus, Profibus, or Ethernet/IP can significantly enhance interoperability with existing plant-wide networks.

The long-term value of this VFD is amplified by its energy efficiency, which translates to significant operational cost savings over the product's lifecycle, especially in continuous operation scenarios. Furthermore, its robust design and comprehensive protection features contribute to reduced downtime and maintenance, safeguarding investments in connected machinery. The availability of firmware updates and technical support from OULU ensures the drive remains compatible with evolving industrial standards and technologies.

Integration with Industrial Internet of Things (IIoT) platforms is increasingly becoming a key factor in long-term value. While specific IIoT integration capabilities for this model require direct verification with the manufacturer, many modern VFDs offer features that support data logging, remote monitoring, and predictive maintenance through network connectivity. This allows for leveraging the drive's operational data to optimize processes, anticipate failures, and improve overall operational intelligence.
