INVT GD350A-560G-4 High Performance General VFD Drive

The INVT GD350A-560G-4 High Performance General VFD Drive represents a pinnacle of modern motor control technology, engineered for demanding industrial applications. This variable frequency drive (VFD) delivers exceptional performance, precision, and reliability, making it an indispensable component for optimizing machinery across diverse sectors. Its core advantages lie in its advanced control algorithms, robust construction, and comprehensive feature set designed to enhance energy efficiency, extend equipment lifespan, and improve process control.

| Parameter              | Specification                                   |

| :--------------------- | :---------------------------------------------- |

| Model                  | GD350A-560G-4                                   |

| Input Voltage          | 3-Phase, 380V/400V/415V/440V (-15% to +10%)       |

| Output Capacity (kW)   | 560 kW                                          |

| Output Capacity (HP)   | 700 HP                                          |

| Output Voltage         | 0-Input Voltage                                 |

| Rated Output Current   | 1000 A                                          |

| Frequency Range        | 0-300 Hz                                        |

| Control Method         | Sensorless Vector Control, V/f Control          |

| Overload Capacity      | 150% for 60s, 180% for 10s                        |

| Braking Unit           | Built-in (Optional external brake resistor)     |

| Protection Level       | IP20 (Standard)                                 |

| Ambient Temperature    | -20°C to +40°C (Derating above +40°C)           |

| Altitude               | < 1000m (Derating above 1000m)                  |

| Communication          | RS485 (Modbus RTU standard), Optional Fieldbus |

The INVT GD350A-560G-4 distinguishes itself through its sophisticated control capabilities, including advanced sensorless vector control that provides precise torque and speed regulation even without encoder feedback. This technology significantly enhances dynamic response and improves the accuracy of complex processes. Its robust design ensures longevity in harsh industrial environments, while features like a built-in braking unit offer efficient deceleration and safety. The drive's market positioning is firmly within the high-performance VFD segment, catering to applications where energy savings, process optimization, and motor protection are paramount. Its competitive edge lies in its combination of advanced features, high power output, and INVT's reputation for reliability.

Key application scenarios for the INVT GD350A-560G-4 are widespread, encompassing heavy-duty industrial machinery. This includes its use in large pumps and fans in HVAC systems, ensuring optimal airflow and water pressure while minimizing energy consumption. It is also critical for driving conveyors and material handling equipment in manufacturing and logistics, providing smooth acceleration and precise speed control for efficient throughput. Furthermore, its high power rating makes it suitable for compressors, extruders, and mixers in chemical processing, plastics manufacturing, and food production, where consistent operation and precise torque control are essential for product quality.

Practical system integration of the INVT GD350A-560G-4 requires careful attention to electrical connections and parameter configuration. For wiring, ensure that the main power input terminals (L1, L2, L3) and motor output terminals (T1, T2, T3) are securely connected with appropriately sized conductors to handle the high currents. Grounding is critical for safety and noise reduction. The control input terminals should be wired according to the specific application's needs, utilizing digital inputs for start/stop commands and speed selection, and analog inputs for speed reference signals. Initial commissioning involves setting fundamental parameters such as motor data (rated voltage, current, frequency, poles), operating mode (V/f or sensorless vector), and acceleration/deceleration times. Advanced parameter setup may include current loop gain, boost settings, and protection thresholds to optimize performance for the connected motor and load. Programming via the RS485 interface using the Modbus RTU protocol allows for remote monitoring, control, and integration into SCADA or PLC systems.

Operation and risk mitigation for the INVT GD350A-560G-4 are primarily focused on safety and preventing operational disruptions. Always ensure the VFD is properly grounded and that the motor is correctly wired before applying power. During operation, monitor motor temperature and drive status through the keypad display or communication interface. Common troubleshooting involves checking for error codes displayed on the VFD; for instance, an "OC" (Overcurrent) fault might indicate a load issue or rapid acceleration, while an "OV" (Overvoltage) fault could point to regenerative braking issues or input power fluctuations. Adhering to environmental conditions, such as maintaining the specified ambient temperature and avoiding excessive dust or moisture, is crucial. Regular inspection of cooling fans and heatsinks helps prevent overheating.

Scalability and long-term value are inherent in the design of the INVT GD350A-560G-4. Its modular design and support for standard communication protocols like Modbus RTU facilitate integration into existing automation architectures and future upgrades. For IIoT integration, the drive can be connected to network gateways or edge devices, enabling real-time data acquisition for performance monitoring, predictive maintenance, and energy management. This connectivity allows for remote diagnostics, parameter adjustments, and performance optimization, maximizing the operational lifespan and return on investment. Compatibility with a wide range of motors, including those with varying characteristics, further enhances its flexibility and long-term applicability in evolving industrial environments.
