Moxa ioLogik R1241 Wireless Data Acquisition & Transmission I/O

The Moxa ioLogik R1241 is a robust wireless data acquisition and transmission I/O module designed for demanding industrial environments. It offers a versatile solution for remote monitoring and control applications, characterized by its reliable RS-485 communication, dual-port design with built-in repeater, and flexible analog output capabilities. The unit supports high-speed data transmission over long distances, simplifying complex automation systems and reducing maintenance overhead. Its compact form factor and DIN-rail mounting options ensure straightforward integration into existing control cabinets.

Product Specifications

| Feature                 | Specification                                                     |

| :---------------------- | :---------------------------------------------------------------- |

| Series                  | ioLogik R1200 Series                                              |

| Analog Outputs (AOs)    | 4                                                                 |

| Output Ranges           | 0 to 10 VDC, 0 to 20 mA, 4 to 20 mA                                 |

| Converter Resolution    | 12-bit                                                            |

| Accuracy (AO @ 25°C)    | ±0.1% FSR                                                         |

| Accuracy (AO @ -10 to 60°C) | ±0.3% FSR                                                         |

| Serial Standards        | RS-485                                                            |

| Serial Ports            | 2                                                                 |

| Baudrate                | 1200 bps to 921.6 kbps                                            |

| Isolation               | 3k VDC or 2k Vrms                                                 |

| Input Voltage           | 12 to 48 VDC                                                      |

| Power Consumption       | 343 mA @ 24 VDC                                                   |

| Operating Temperature   | -10 to 75°C (14 to 167°F)                                         |

| Wide Temp. Models       | -40 to 85°C (-40 to 185°F)                                        |

| Dimensions              | 27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)                          |

| Weight                  | 200 g (0.44 lb)                                                   |

| Housing                 | Plastic                                                           |

| Mounting                | DIN-rail, Wall                                                    |

| Certifications          | CE, FCC, UL 508                                                   |

| Supported Protocols     | Modbus RTU Slave                                                  |

| ESD Protection          | 15 kV                                                             |

| Surge Protection        | 1 kV                                                              |

Core Features & Market Positioning

The Moxa ioLogik R1241 distinguishes itself in the industrial automation market through its emphasis on ease of deployment and maintenance, coupled with robust communication capabilities. The dual RS-485 ports with a built-in repeater simplify network expansion and enhance signal integrity over long distances, directly addressing a common pain point in industrial SCADA and telemetry systems. Its support for multidrop configurations further streamlines installation, reducing the need for complex wiring and extensive configuration. The inclusion of USB for parameter configuration and firmware upgrades, alongside RS-485, provides significant flexibility for field technicians, minimizing downtime. Moxa positions the ioLogik R1241 as a cost-effective, dependable, and highly maintainable remote I/O solution, ideal for engineers seeking to reduce deployment effort and enhance operational efficiency. Its Click&Go control logic and active monitoring technology enable straightforward integration into IIoT applications, further solidifying its market appeal for modern industrial automation needs.

Key Application Scenarios

The Moxa ioLogik R1241 finds extensive application in scenarios requiring reliable remote data acquisition and transmission. Its analog output capabilities make it suitable for controlling actuators, variable speed drives, or other industrial equipment based on remote commands or data from a central system. Common use cases include:

  Energy Monitoring and Management: Collecting data from power meters, substations, and renewable energy sources for real-time analysis and control.  Facility Monitoring: Overseeing environmental conditions, equipment status, and utility consumption in large industrial plants, commercial buildings, or remote infrastructure.  Machine OEM Applications: Integrating into packaged equipment for remote diagnostics, performance monitoring, and operational adjustments.  Water and Wastewater Management: Monitoring flow rates, pressure levels, and chemical dosages in distributed water treatment facilities or pipeline networks.  Environmental Sensing: Deploying in remote or hazardous locations to gather data from sensors for air quality, weather monitoring, or pollution control.  Asset Tracking and Telemetry: Transmitting status and operational data from remotely located assets like pumps, generators, or mobile equipment.

The device's robust design and wide operating temperature range (with specific models available for -40 to 85°C) make it particularly well-suited for harsh environmental conditions common in these sectors.

Practical System Integration Guidance

Integrating the Moxa ioLogik R1241 into an industrial system is designed to be straightforward, leveraging its user-friendly features. For initial setup and configuration, the ioSearch software is indispensable. This utility allows engineers to quickly access device status and settings via a graphical user interface. Firmware updates can be seamlessly applied through the same software, either over the RS-485 network or via a USB drive, significantly reducing on-site maintenance time.

The dual RS-485 ports facilitate network expansion and redundancy. When connecting multiple ioLogik devices on a single RS-485 bus, the ioSearch software simplifies the process by allowing configuration and duplication of baud rates and modes, eliminating the need for manual dial adjustments common in older systems. Wiring involves standard I/O cables (16 to 26 AWG) and power cables (12 to 24 AWG), connecting to screw-fastened Euroblock terminals. The unit supports DIN-rail mounting, ensuring a clean and organized installation within control cabinets. The Modbus RTU slave protocol is natively supported, enabling easy integration with existing SCADA systems and PLCs.

Operation and Risk Mitigation

Operating the Moxa ioLogik R1241 is primarily managed through its configuration software and the Modbus RTU protocol. For safe operation, adherence to power input specifications (12 to 48 VDC) is critical. The device is equipped with protection against ESD (15 kV) and surge (1 kV), mitigating common electrical risks in industrial settings.

In terms of troubleshooting, the LED indicators (PWR, RDY, P1, P2) provide immediate visual feedback on the device's status and communication. For communication issues, verifying RS-485 wiring integrity and ensuring correct baud rate and parity settings are paramount. The dual RS-485 port design offers a built-in repeater and redundancy option; if one port experiences issues, the system can often continue operating through the second port, allowing for planned maintenance or repair without complete system shutdown. The user manual provides detailed guidance on error codes and diagnostic procedures, though specific fault codes are not prominently detailed in product descriptions.

Scalability & Long-Term Value

The Moxa ioLogik R1241 is engineered for scalability and long-term value within industrial automation architectures. Its dual RS-485 ports and support for multidrop configurations allow for easy expansion of data acquisition points on a single communication backbone. This architecture supports the connection of numerous devices, allowing systems to grow incrementally as demand increases.

The device's compatibility with the Modbus RTU protocol ensures seamless integration with a vast array of existing SCADA systems, PLCs, and HMI panels, preserving investments in established infrastructure. Furthermore, Moxa's commitment to providing easy-to-use software like ioSearch for configuration and firmware updates reduces the total cost of ownership by simplifying maintenance and future upgrades. The availability of wide-temperature models further enhances its long-term value by ensuring reliable operation across a broader range of challenging environmental conditions. The device is designed to facilitate IIoT integration, making it a forward-compatible solution for smart manufacturing and Industry 4.0 initiatives.

Frequently Asked Questions (FAQs)

What are the primary advantages of using the Moxa ioLogik R1241 for wireless data acquisition?

The ioLogik R1241 excels in simplifying complex industrial networks. Its dual RS-485 ports with a built-in repeater enhance signal reliability over long distances. The device reduces installation costs through multidrop communication support. Firmware updates and parameter configurations are easily managed via USB, minimizing site visits.

Can the Moxa ioLogik R1241 operate in extreme environmental conditions?

Yes, standard models offer an operating temperature range of -10 to 75°C. For more demanding environments, wide-temperature models are available, capable of operating from -40 to 85°C. This ensures reliable data acquisition even in harsh industrial settings.

How does the Moxa ioLogik R1241 facilitate system integration and maintenance?

Moxa's ioSearch software provides a user-friendly interface for configuration and firmware updates. The dual RS-485 ports simplify network expansion, while multidrop capability reduces wiring complexity. This design minimizes deployment effort and ongoing maintenance labor.

What industrial protocols does the Moxa ioLogik R1241 support for communication?

The ioLogik R1241 primarily supports the Modbus RTU protocol as a slave device. This widely adopted industrial standard ensures compatibility with numerous SCADA systems, PLCs, and data acquisition platforms.

How is firmware updated on the Moxa ioLogik R1241?

Firmware can be updated through two convenient methods. The first is via a USB drive, allowing for quick, on-site updates. Alternatively, firmware can be upgraded remotely over an RS-485 connection using Moxa's ioSearch software.

What are the key technical specifications for the analog outputs of the ioLogik R1241?

The unit features 4 analog outputs with a 12-bit resolution. These outputs support standard ranges of 0-10 VDC and 0-20/4-20 mA. Accuracy is rated at ±0.1% FSR at 25°C, with ±0.3% FSR across the wider operating temperature range.

What type of connectors are used for power and I/O on the Moxa ioLogik R1241?

The device utilizes screw-fastened Euroblock terminals for both power input and analog output connections. This robust terminal type ensures secure and reliable connections in industrial environments.

Does the Moxa ioLogik R1241 offer any form of network redundancy?

Yes, the ioLogik R1241 features dual RS-485 ports. This design allows for the implementation of network redundancy by connecting to two independent RS-485 networks or using the second port as a backup.

What are the power requirements for the Moxa ioLogik R1241?

The ioLogik R1241 requires a DC power input ranging from 12 to 48 VDC, with a nominal requirement of 24 VDC. Power consumption is approximately 343 mA at 24 VDC.

What physical installation methods are supported by the Moxa ioLogik R1241?

The unit is designed for industrial cabinet mounting and supports both DIN-rail mounting and wall mounting. Its compact dimensions ensure it fits easily into space-constrained control panels.
