Moxa EDS-2016-ML 16-Port Gigabit Industrial Managed Switch

The Moxa EDS-2016-ML 16-Port Gigabit Industrial Managed Switch is engineered for demanding industrial environments, offering robust connectivity and advanced management capabilities. This switch boasts 16 Gigabit Ethernet ports, ensuring high-speed data transfer crucial for modern industrial automation and communication networks. Its key advantages lie in its industrial-grade design, supporting wide operating temperature ranges and providing reliable performance under harsh conditions. Essential technical parameters include its compact form factor, DIN-rail mounting, and support for various industrial protocols, making it a versatile solution for diverse applications. The EDS-2016-ML is designed for seamless integration into supervisory control and data acquisition (SCADA) systems, programmable logic controller (PLC) networks, and other critical infrastructure.

Product Specifications

| Feature              | Specification                                    |

| :------------------- | :----------------------------------------------- |

| Port Type            | 16 x 10/100/1000BaseT(X) Gigabit Ethernet Ports    |

| Power Input          | 24 VDC (12-48 VDC)                               |

| Operating Temperature | -40 to 75 °C                                     |

| Mounting             | DIN-rail, Wall-mount                             |

| Management           | Managed (Web, Telnet, Console, SNMP)             |

| MTBF                 | 500,000+ hours                                   |

| Dimensions           | 60 x 140 x 110 mm                                |

| Ingress Protection   | IP30                                             |

Core Features & Market Positioning

The Moxa EDS-2016-ML distinguishes itself in the industrial networking market through its combination of high-density Gigabit ports and comprehensive management features. Unlike many unmanaged switches, the EDS-2016-ML offers granular control over network traffic, Quality of Service (QoS) for prioritizing critical data, and robust security features to protect industrial networks from cyber threats. Its industrial-grade construction, evidenced by its wide operating temperature range and high Mean Time Between Failures (MTBF), positions it as a superior choice for applications where reliability is paramount. This switch is designed to meet the stringent demands of sectors such as manufacturing, transportation, and energy, where network uptime directly impacts operational efficiency and safety. The inclusion of advanced protocols like Modbus TCP and LLDP further enhances its integration capabilities within industrial automation ecosystems.

Key Application Scenarios

The Moxa EDS-2016-ML 16-Port Gigabit Industrial Managed Switch is ideally suited for demanding industrial applications requiring high bandwidth and reliable network connectivity. Its 16 Gigabit ports facilitate high-speed data aggregation from numerous sensors, cameras, and control systems in manufacturing plants, enabling real-time monitoring and analysis. In transportation systems, such as intelligent traffic management or railway communication networks, the switch's robust design ensures uninterrupted data flow for critical operations. Furthermore, in the energy sector, including substations and power generation facilities, its resilience to harsh environmental conditions and advanced management capabilities are essential for maintaining grid stability and operational efficiency. The ability to support complex network topologies and prioritize traffic makes it a cornerstone for advanced Industrial Internet of Things (IIoT) deployments.

Practical System Integration Guidance

Integrating the Moxa EDS-2016-ML into an industrial network is streamlined through its user-friendly management interface and standard industrial mounting options. For installation, the switch can be securely mounted on a DIN-rail or directly to a wall using the provided brackets, ensuring a stable physical connection in control cabinets. Network configuration is accessible via multiple methods, including a web browser, Telnet, console port, or SNMP, allowing network administrators to select their preferred management tool. Initial setup often involves assigning an IP address and configuring basic network parameters like VLANs and QoS. For secure remote access and management, establishing an SNMP v3 connection or using secure shell (SSH) for Telnet sessions is recommended. Power is supplied via a 24 VDC input, supporting a wide voltage range for compatibility with various industrial power sources.

Operation and Risk Mitigation

Operating the Moxa EDS-2016-ML requires adherence to standard industrial network best practices to ensure optimal performance and longevity. Regular firmware updates are crucial for patching security vulnerabilities and incorporating new features; users should consult Moxa's support portal for the latest releases. To mitigate common troubleshooting issues, it is important to verify physical connections, including Ethernet cable integrity and power supply stability. Network segmentation using VLANs can prevent broadcast storms and enhance security. In terms of risk, the switch’s industrial design inherently offers high resilience; however, extreme environmental factors beyond its specified operating range, such as exposure to corrosive elements or excessive vibration, should be avoided. Proper grounding and surge protection for power inputs are also critical for preventing electrical damage.

Scalability & Long-Term Value

The Moxa EDS-2016-ML 16-Port Gigabit Industrial Managed Switch provides significant scalability and long-term value for evolving industrial networks. Its 16 high-speed Gigabit ports offer ample capacity for current data demands and future expansion, accommodating the increasing number of connected devices in IIoT environments. The managed nature of the switch allows for advanced network segmentation and traffic management, which can be easily reconfigured as network requirements change. Compatibility with Moxa's broader portfolio of industrial networking products ensures seamless integration into existing or planned infrastructure, facilitating a cohesive and robust system. Furthermore, the switch's support for industry-standard protocols and its robust construction contribute to a prolonged service life, reducing the total cost of ownership and minimizing the need for frequent replacements.

Frequently Asked Questions (FAQs)

What are the primary benefits of using a managed industrial switch like the Moxa EDS-2016-ML?

Managed switches offer superior network control and visibility, allowing for traffic prioritization and security configurations. This is critical for mission-critical industrial applications where downtime is costly. The EDS-2016-ML provides this granular control.

Managed switches enable advanced features like VLANs and QoS, essential for optimizing industrial network performance. They also offer robust security protocols to protect sensitive operational data. These capabilities are standard on the EDS-2016-ML.

The EDS-2016-ML's management features aid in proactive troubleshooting and network optimization, reducing operational risks and ensuring higher system availability. This enhances overall industrial automation efficiency.

Can the Moxa EDS-2016-ML be integrated into existing SCADA systems?

Yes, the EDS-2016-ML is designed for seamless integration with SCADA systems. Its support for protocols like Modbus TCP facilitates communication with SCADA software.

The switch's robust networking capabilities ensure reliable data acquisition from field devices to the SCADA host. This is vital for real-time process monitoring and control.

Its industrial-grade design guarantees stable operation within the harsh environments often found in SCADA deployment sites. This ensures consistent data flow.

What are the power requirements for the Moxa EDS-2016-ML?

The Moxa EDS-2016-ML operates on a 24 VDC power input, with a wide voltage tolerance from 12 to 48 VDC. This flexibility accommodates various industrial power supplies.

This wide voltage range enhances reliability in environments where power fluctuations might occur. It also simplifies power sourcing and installation.

Dual power inputs are often supported for redundancy, ensuring continuous operation even if one power source fails. This is a key feature for industrial uptime.

How does the Gigabit Ethernet capability of the EDS-2016-ML benefit industrial networks?

Gigabit Ethernet ports provide significantly higher data throughput compared to Fast Ethernet, enabling faster data transfer for applications like video surveillance and large data logging. This is crucial for modern industrial data demands.

This high bandwidth is essential for industrial automation systems that process large volumes of sensor data or require real-time communication between multiple high-performance devices. The EDS-2016-ML supports this.

With 16 Gigabit ports, the EDS-2016-ML can handle the aggregation of data from numerous sources, preventing bottlenecks and ensuring the efficient operation of complex industrial networks. This increases overall network capacity.

What environmental conditions can the Moxa EDS-2016-ML withstand?

The EDS-2016-ML is built for industrial environments, featuring a wide operating temperature range of -40 to 75 °C. This ensures reliable performance in extreme hot and cold conditions.

It has an IP30 rating, offering protection against solid objects greater than 2.5 mm, though it's not waterproof. This indicates suitability for controlled industrial settings.

The switch's robust construction is designed to withstand vibration and shock commonly found in industrial machinery and mobile applications, ensuring physical durability. This enhances its longevity.

What are the common management features available on the Moxa EDS-2016-ML?

The EDS-2016-ML supports multiple management interfaces including Web, Telnet, Console, and SNMP. This provides flexibility for network administrators to configure and monitor the switch.

Key management functions include VLANs for network segmentation, QoS for prioritizing traffic, and port mirroring for network diagnostics. These features enhance network performance and security.

It also offers advanced features like Link Aggregation Control Protocol (LACP) for increased bandwidth and redundancy, and IGMP snooping for efficient multicast traffic management. These optimize network efficiency.

What is the MTBF rating for the Moxa EDS-2016-ML, and why is it important?

The Moxa EDS-2016-ML boasts a Mean Time Between Failures (MTBF) rating of over 500,000 hours. This signifies a very high level of reliability and durability.

A high MTBF is critical in industrial settings where network downtime can lead to significant production losses and safety hazards. It indicates long-term operational stability.

This statistic assures users that the switch is engineered for continuous, long-term operation under demanding industrial conditions, reducing maintenance needs and operational costs. It's a key indicator of quality.

How is the Moxa EDS-2016-ML typically mounted in an industrial cabinet?

The EDS-2016-ML is designed for easy installation in industrial control cabinets. It supports standard DIN-rail mounting, which is a common and secure method in industrial settings.

Alternatively, it can be mounted directly onto a wall or panel using provided mounting brackets. This offers flexibility depending on cabinet space and layout.

Proper mounting ensures the switch is securely positioned, minimizing vibration and allowing for adequate airflow, which is important for maintaining optimal operating temperatures and performance. This contributes to reliability.

What are the security features offered by the Moxa EDS-2016-ML?

The EDS-2016-ML includes managed security features like IEEE 802.1X authentication to control network access. This ensures only authorized devices can connect to the network.

It supports SNMPv3 for secure network management, encrypting management traffic to prevent unauthorized access or tampering. This protects against cyber threats.

VLANs can be configured to segment the network, isolating different segments and limiting the spread of potential security breaches. This enhances overall network security posture.

Does the Moxa EDS-2016-ML support any industrial automation protocols directly?

Yes, the EDS-2016-ML often supports industrial protocols such as Modbus TCP. This facilitates communication and integration with PLCs and SCADA systems.

Support for protocols like LLDP (Link Layer Discovery Protocol) helps in network topology discovery and management, simplifying maintenance and troubleshooting in industrial environments. This aids in system visibility.

Its robust Ethernet capabilities ensure reliable data exchange for time-sensitive industrial control applications, even when carrying protocol-specific traffic. This ensures deterministic communication.
