Siemens 3RT2018-1AP01 High Capacity AC Contactor 230VAC 16A 3NO

The Siemens 3RT2018-1AP01 is a high-capacity AC contactor engineered for robust and reliable control of industrial electrical circuits. This specific model boasts a 230VAC coil voltage and a substantial 16A continuous current rating, featuring three normally open (NO) auxiliary contacts. Its compact SIRIUS design ensures space-saving installation, while its inherent reliability makes it a preferred choice for demanding motor control and switching applications. With exceptional switching cycles and a broad operating temperature range, the 3RT2018-1AP01 delivers consistent performance in harsh industrial environments, underpinning critical power distribution and automation systems.

Siemens 3RT2018-1AP01: Product Specifications

| Feature                | Specification                               |

| :--------------------- | :------------------------------------------ |

| Product Type           | AC Contactor                                |

| Series                 | SIRIUS 3RT2                                 |

| Model Number           | 3RT2018-1AP01                               |

| Coil Voltage           | 230 VAC                                     |

| Conventional Free-air Thermal Current (Ith) | 16 A                                        |

| Number of NO Contacts  | 3                                           |

| Number of NC Contacts  | 0                                           |

| Auxiliary Contact Type | Normally Open (NO)                          |

| Control Circuit Voltage | 230 VAC                                     |

| AC-3 Power Breaking Capacity | 7.5 kW at 400 V                             |

| Mounting Type          | DIN rail or screw mounting                  |

| Dimensions (H x W x D) | 58 mm x 45 mm x 74 mm                       |

| Protection Rating      | IP20                                        |

| Operating Temperature  | -25 to +60 °C                               |

| Standards Compliance   | IEC/EN 60947-4-1, IEC/EN 60947-5-1          |

Core Features & Market Positioning

The Siemens 3RT2018-1AP01 distinguishes itself through its robust construction and adherence to stringent international standards, such as IEC/EN 60947-4-1. This commitment to quality ensures superior operational longevity and safety, crucial for industrial automation. Its integration within the broader Siemens SIRIUS modular system offers unparalleled flexibility and compatibility, allowing for seamless incorporation into existing or new control panels. This makes the 3RT2018-1AP01 a highly competitive option for applications demanding reliability and ease of integration, positioning it as a trusted component for critical power switching. The contactor's design prioritizes user safety and efficient thermal management, contributing to its reliable performance under continuous load conditions.

Key Application Scenarios

This Siemens contactor is predominantly utilized in motor control applications, serving to start, stop, and reverse three-phase induction motors. Its 16A rating makes it suitable for a wide range of industrial machinery, including pumps, fans, compressors, and conveyor systems. Furthermore, the 3RT2018-1AP01 finds application in general power switching for lighting circuits, heating systems, and other industrial loads where reliable AC switching is paramount. Its three normally open contacts provide flexibility for basic control logic and signaling within automation systems. The 230VAC coil voltage is standard in many industrial power distribution networks, simplifying integration into existing control architectures.

Practical System Integration Guidance

Integrating the Siemens 3RT2018-1AP01 is straightforward due to its DIN rail or screw mounting options and clear terminal markings. For motor control, the main power terminals (L1, L2, L3) connect to the power supply, and the corresponding motor terminals (T1, T2, T3) connect to the motor windings. The coil terminals (A1, A2) are connected to the 230VAC control voltage source. When used with control circuits, ensure the control voltage precisely matches the 230VAC rating to prevent damage. Auxiliary contacts can be wired into control logic for feedback or interlocking purposes. Proper wire sizing according to the 16A rating and local electrical codes is essential for safe and effective operation.

Operation and Risk Mitigation

Operating the Siemens 3RT2018-1AP01 involves energizing its 230VAC coil to close the main power contacts, thereby completing the circuit to the load, typically a motor. De-energizing the coil opens the contacts, disconnecting the load. Safety is paramount; always ensure power is isolated before installation or maintenance. The IP20 protection rating means it should be installed in an enclosure to prevent accidental contact with live parts. Overloading the contactor beyond its 16A rating or using it with inappropriate coil voltages can lead to premature failure and potential hazards. Regular inspection for signs of wear, such as contact pitting or overheating, is recommended to ensure continued safe operation.

Scalability & Long-Term Value

The Siemens 3RT2018-1AP01 benefits from the extensive SIRIUS innovation ecosystem, offering excellent scalability and long-term value. It can be easily expanded with additional auxiliary contact blocks for more complex control logic or combined with other SIRIUS components like overload relays (e.g., 3RU21 or 3RB3) for comprehensive motor protection. Its compatibility with Siemens' broader automation platforms, including SIMATIC PLCs, allows for seamless integration into advanced digitalized manufacturing environments and IIoT solutions. This future-proof design ensures that the 3RT2018-1AP01 remains a relevant and valuable component throughout the lifecycle of an industrial installation.
