Moxa EDS-2005-ELP 4-Port Industrial PoE+ Power over Ethernet Switch

The Moxa EDS-2005-ELP is a robust 4-port industrial PoE+ Power over Ethernet switch engineered for demanding environments, delivering reliable network connectivity and power to connected devices. This compact switch boasts essential features such as its wide operating temperature range, ensuring functionality in extreme conditions, and its support for IEEE 802.3af/at PoE standards, providing up to 30 watts per port to power devices like IP cameras, wireless access points, and industrial sensors. Its DIN-rail mounting capability simplifies installation within control cabinets, making it an ideal solution for factory automation, intelligent transportation systems, and outdoor surveillance applications.

| Feature                     | Specification                                 |

| :-------------------------- | :-------------------------------------------- |

| Ports                       | 4 x 10/100BaseT(X) RJ45 ports                 |

| PoE Ports                   | 4 x 10/100BaseT(X) RJ45 ports                 |

| PoE Standard                | IEEE 802.3af/at                               |

| Max. PoE Power per Port     | 30 Watts                                      |

| Total PoE Power Budget      | 120 Watts (maximum)                           |

| Input Voltage               | 24/48 VDC (9.6-60 VDC)                         |

| Operating Temperature       | -40 to 75 °C (-40 to 167 °F)                  |

| Mounting                    | DIN-rail                                      |

| Enclosure                   | IP30 protection                               |

| Dimensions                  | 30 x 104 x 84 mm (1.18 x 4.09 x 3.31 in)        |

| Mean Time Between Failures  | >500,000 hours                                |

| Warranty                    | 5 years                                       |

Core Features & Market Positioning

The Moxa EDS-2005-ELP distinguishes itself through its industrial-grade construction and advanced Power over Ethernet capabilities. Its ability to operate reliably within a wide temperature range of -40 to 75°C positions it as a superior choice for harsh environments where standard commercial switches would fail. The switch adheres to IEEE 802.3af and 802.3at standards, offering up to 30 watts of power per port, a critical advantage for powering high-demand industrial devices like PTZ cameras and industrial IoT sensors without the need for local power supplies. This integrated power and data solution significantly reduces installation complexity and cabling costs, a key differentiator in industrial networking projects. Its robust design, including an IP30-rated enclosure and extensive MTBF (Mean Time Between Failures) rating, underscores Moxa's commitment to product longevity and operational uptime in mission-critical applications.

Key Application Scenarios

This industrial PoE+ switch is exceptionally well-suited for deployment in ruggedized environments and complex network infrastructures. In factory automation, it efficiently powers and connects sensors, actuators, and machine vision cameras directly on the production floor, facilitating real-time data acquisition and control. For intelligent transportation systems (ITS), the EDS-2005-ELP provides robust connectivity for traffic monitoring cameras, variable message signs, and roadside communication units, even in variable weather conditions. Its outdoor surveillance capabilities are paramount, enabling the reliable deployment of high-resolution IP cameras and access points in remote or exposed locations, supported by its wide operating temperature range and IP30 protection. Furthermore, its compact DIN-rail mountable form factor makes it ideal for integration into existing control cabinets and enclosures in sectors such as oil and gas, utilities, and building automation.

Practical System Integration Guidance

Integrating the Moxa EDS-2005-ELP into an industrial network is straightforward due to its plug-and-play design and standard Ethernet interface. The switch features four 10/100BaseT(X) RJ45 ports, allowing for easy connection to a wide array of industrial devices. Power is supplied via a 24/48 VDC input (9.6-60 VDC range), accommodating diverse power setups in industrial facilities. When deploying PoE devices, ensure the total power consumption of all connected devices does not exceed the switch's 120-watt budget. For installation, the DIN-rail mounting mechanism simplifies physical integration into standard industrial enclosures. No complex software configuration is typically required for basic network operation, but for advanced features like VLANs or QoS (if supported by the specific model variant), consult the comprehensive Moxa management software or web interface documentation.

Operation and Risk Mitigation

Operating the Moxa EDS-2005-ELP requires attention to environmental conditions and power management. While designed for extreme temperatures, ensuring adequate ventilation within enclosures can further enhance longevity. The primary operational risk involves exceeding the total PoE power budget, which could lead to unstable operation or failure to power devices. Monitor connected device power draw to remain within the 120-watt limit. For troubleshooting, basic checks include verifying power supply connections and ensuring all Ethernet cables are securely seated and undamaged. LED indicators on the front panel provide visual status for power, network activity, and PoE status, aiding in rapid fault diagnosis. Standard industrial safety practices should be followed during installation and maintenance, including proper grounding and disconnecting power before performing any physical connections or disconnections.

Scalability & Long-Term Value

The Moxa EDS-2005-ELP offers excellent long-term value and scalability within industrial networking. Its robust design and high MTBF rating ensure a long operational lifespan, minimizing the need for frequent replacements and reducing total cost of ownership. The switch's compatibility with standard industrial protocols and Ethernet infrastructure makes it easy to integrate into existing or future network upgrades. As industries move towards Industry 4.0 and the Industrial Internet of Things (IIoT), the EDS-2005-ELP provides a reliable foundation for connecting more intelligent devices, enabling enhanced data collection and analysis. Its ability to power multiple PoE devices directly simplifies the expansion of smart sensor networks and IoT deployments, supporting a scalable approach to industrial automation and digital transformation initiatives.

Frequently Asked Questions

What are the primary benefits of the Moxa EDS-2005-ELP?

The Moxa EDS-2005-ELP offers robust industrial-grade performance and reliable network connectivity. Its key advantage is the integration of Power over Ethernet (PoE+), simplifying device deployment and reducing cabling needs. The switch is built to withstand harsh environmental conditions, including a wide operating temperature range, ensuring uptime in demanding industrial settings.

How does the PoE+ functionality of the EDS-2005-ELP work?

The switch supports IEEE 802.3af and 802.3at standards, delivering up to 30 watts of power per port simultaneously. This enables the powering of high-demand devices like IP cameras, wireless access points, and industrial sensors directly through the Ethernet cable. The total power budget across all ports is 120 watts, allowing for flexible deployment of multiple powered devices.

What technical specifications are crucial for deploying the Moxa EDS-2005-ELP?

Key specifications include its four 10/100BaseT(X) RJ45 ports for network connectivity. The wide operating temperature range of -40 to 75°C is critical for industrial environments. Input voltage compatibility with 24/48 VDC (9.6-60 VDC) ensures flexible power integration. Its DIN-rail mounting and IP30 enclosure facilitate easy installation and protection.

Can the Moxa EDS-2005-ELP be used in outdoor environments?

Yes, the Moxa EDS-2005-ELP is designed for harsh conditions, including outdoor use. Its wide operating temperature range of -40 to 75°C allows it to function reliably in extreme heat and cold. The IP30 enclosure offers a degree of protection against dust and solid objects, making it suitable for many outdoor surveillance and communication applications.

What types of devices can be powered by the PoE+ ports?

The PoE+ ports can power a wide range of devices that support the IEEE 802.3af or 802.3at standards. This includes high-resolution IP surveillance cameras (including PTZ models), industrial IoT sensors, wireless access points, VoIP phones, and other network-enabled equipment. The 30W per port capability supports more power-hungry devices.

How is the EDS-2005-ELP installed in an industrial control panel?

Installation is simplified by its DIN-rail mounting capability, a standard in industrial control cabinets. The switch can be easily snapped onto a 35mm DIN rail. Ensure adequate ventilation within the enclosure to maintain optimal operating temperatures and prolong the device's lifespan, especially when powering multiple PoE devices.

What are the power requirements for the Moxa EDS-2005-ELP itself?

The switch requires a DC power input, typically between 24 VDC or 48 VDC. The acceptable input voltage range is quite wide, from 9.6 VDC to 60 VDC. This flexibility allows it to be integrated into various existing industrial power supply systems. It's essential to use a reliable power source within this specified range.

What is the total power budget for all PoE+ ports combined?

The Moxa EDS-2005-ELP has a total PoE power budget of 120 watts. This means the sum of the power consumed by all PoE-powered devices connected to the switch cannot exceed 120 watts. It's crucial to calculate the power requirements of your connected devices to ensure you do not exceed this limit, which could cause instability.

What are common troubleshooting steps if a PoE device is not receiving power?

First, verify that the connected device is indeed PoE-compliant (IEEE 802.3af/at). Check the power LED status on the switch port. Ensure the total power consumption of all devices does not exceed the 120W budget. Try connecting the device to a different port or swapping cables to rule out individual port or cable issues.

How does this switch contribute to Industrial IoT (IIoT) and Industry 4.0 initiatives?

The EDS-2005-ELP provides a foundational networking layer for IIoT by enabling the reliable connection and powering of numerous sensors and edge devices. This facilitates data collection from the factory floor or remote assets, crucial for real-time monitoring and analytics. Its industrial robustness ensures these connections remain stable in demanding operational environments.
