Siemens 1FL6062-1AC61-2LB1 High Precision Power Low Inertia Brake Motor

The Siemens 1FL6062-1AC61-2LB1 is a high-precision, low-inertia brake motor engineered for demanding industrial automation tasks. This motor excels in applications requiring rapid acceleration, deceleration, and precise positioning. Its core advantages lie in its robust construction, energy efficiency, and integrated safety features, making it a superior choice for robotics, material handling, and machine tool applications. Key technical parameters include a rated power of 4 kW, a voltage rating of 400V, and an IP65 protection class, ensuring reliable operation even in harsh environments. The low inertia design allows for dynamic performance, critical for processes where cycle times and accuracy are paramount.

Siemens 1FL6062-1AC61-2LB1: Technical Specifications

| Parameter             | Value                                     |

| :-------------------- | :---------------------------------------- |

| Motor Type            | Synchronous Motor                         |

| Model Number          | 1FL6062-1AC61-2LB1                        |

| Rated Power           | 4 kW                                      |

| Voltage               | 400V                                      |

| Frequency             | 60 Hz                                     |

| Protection Class      | IP65                                      |

| Inertia               | Low                                       |

| Braking Type          | Integrated Holding Brake                  |

| Frame Size            | 160M                                      |

| Insulation Class      | F                                         |

| Ambient Temperature   | -20°C to +40°C                            |

Core Features & Market Positioning

The Siemens 1FL6062-1AC61-2LB1 distinguishes itself through its exceptional dynamic performance, a direct result of its low-inertia rotor design. This feature enables faster response times, crucial for high-throughput automated systems. The integrated holding brake provides fail-safe operation, ensuring positional integrity even during power outages or emergency stops, a significant advantage over systems requiring external braking components. Its robust IP65 rating signifies excellent protection against dust and water jets, positioning it as a reliable solution for challenging industrial settings. Furthermore, its compatibility with Siemens' broader automation ecosystem, including SINAMICS drives, enhances its value proposition for integrated system solutions.

Key Application Scenarios

This high-precision motor finds extensive application in robotic systems, particularly in pick-and-place operations and assembly lines where rapid and accurate movements are essential. In material handling, it serves automated guided vehicles (AGVs) and conveyor systems that demand precise speed control and reliable stopping capabilities. Machine tool manufacturers leverage the 1FL6062-1AC61-2LB1 for its agility in spindle and axis drives, contributing to improved machining accuracy and reduced cycle times. Its inherent reliability also makes it suitable for packaging machinery, printing presses, and other automated processes where consistent performance and minimal downtime are critical business imperatives.

Practical System Integration Guidance

Integrating the Siemens 1FL6062-1AC61-2LB1 into existing or new automation setups is streamlined due to its standard mounting dimensions and electrical interfaces. Proper wiring to the chosen Siemens drive, such as a SINAMICS S120, is paramount. Ensure the motor and drive are correctly configured within the drive's parameterization software to match the motor's characteristics, including its low inertia and braking function. For the brake, a dedicated power supply is typically required, and its activation/deactivation should be interlinked with the motor's operational status through the control system's logic. Always refer to the detailed Siemens documentation for specific wiring diagrams and commissioning steps relevant to your drive system.

Operation and Risk Mitigation

Safe operation of the Siemens 1FL6062-1AC61-2LB1 hinges on correct parameterization and adherence to safety protocols. The integrated brake acts as a primary safety mechanism, but it should be complemented by appropriate guarding and emergency stop circuits as per machine safety standards. Common troubleshooting may involve checking power supply integrity, encoder feedback signals, and drive status indicators. Overheating can be mitigated by ensuring adequate ventilation and verifying that the motor's load profile does not exceed its rated capacity. Fault codes displayed on the associated Siemens drive provide diagnostic information; consult the drive's manual for specific code interpretations and corrective actions.

Scalability & Long-Term Value

The Siemens 1FL6062-1AC61-2LB1 offers significant long-term value through its seamless integration with Siemens' expansive digital industrial portfolio. It is designed to work harmoniously with SINAMICS drives and SIMOTION or TIA Portal control platforms, facilitating scalability as automation requirements evolve. This compatibility enables easy upgrades and expansions of existing systems without necessitating a complete overhaul of the motor infrastructure. Furthermore, its robust design and high-quality components ensure a long service life, minimizing total cost of ownership. Its potential for integration with Industrial Internet of Things (IIoT) solutions allows for advanced diagnostics, predictive maintenance, and performance optimization through data analytics.
