Schneider ATV630U30N4 Inverter for Automated Production Line Drive 5.8A 3kW IP21

The Schneider Electric ATV630U30N4 inverter is a high-performance variable speed drive engineered to optimize automated production lines, delivering precise motor control and significant energy savings. This robust drive boasts a nominal output current of 5.8A and a power rating of 3kW, housed within an IP21 enclosure for reliable operation in demanding industrial environments. Its advanced features, including sophisticated motor control algorithms and integrated safety functions, position it as a leading solution for applications requiring exceptional drive performance and efficiency. The ATV630 series is designed for seamless integration into complex automation architectures, offering flexibility and durability essential for modern manufacturing.

Product Specifications

| Feature                  | Specification          |

| :----------------------- | :--------------------- |

| Model Number             | ATV630U30N4            |

| Rated Output Current     | 5.8 A                  |

| Power Rating             | 3 kW (4 HP)            |

| Voltage                  | 380-415 V AC           |

| Frequency                | 50/60 Hz               |

| Enclosure Type           | IP21                   |

| Mounting                 | Wall-mount             |

| Control Type             | Sensorless Flux Vector |

| Communication Protocols  | Modbus RTU, Ethernet   |

| Operating Temperature    | -15°C to +50°C         |

| Dimensions (HxWxD)       | Varies by enclosure    |

| Weight                   | Varies by enclosure    |

Core Features & Market Positioning

The Schneider ATV630U30N4 stands out with its advanced Altivar Process technology, offering superior energy efficiency and operational intelligence. Its sensorless flux vector control provides highly accurate speed and torque regulation, crucial for maintaining product quality and process consistency in automated production. The drive's robust design and adherence to international standards ensure longevity and reliability even in harsh industrial settings. Positioned as a premium solution, the ATV630U30N4 competes on its integrated intelligence, advanced diagnostics, and seamless connectivity, making it ideal for industries focused on Industry 4.0 initiatives and maximizing plant uptime.

Key Application Scenarios

This inverter is exceptionally well-suited for a wide array of automated production line applications. It excels in controlling pumps and fans where variable speed operation significantly reduces energy consumption, such as in HVAC systems or water treatment plants. For material handling, the ATV630U30N4 ensures smooth acceleration and deceleration of conveyors, improving product flow and reducing mechanical stress. In packaging machinery, its precise speed control is vital for synchronization and high-throughput operations. Furthermore, its robust performance makes it suitable for process control in the food and beverage, chemical, and pharmaceutical industries, where consistent and reliable operation is paramount.

Practical System Integration Guidance

Integrating the Schneider ATV630U30N4 into an automated production line involves careful consideration of power, control, and communication wiring. The main power terminals require appropriate cable sizing based on the 5.8A rating and local electrical codes to ensure safe and efficient operation. Control wiring for digital and analog inputs/outputs should be shielded to prevent electrical noise interference. For communication, the drive supports Modbus RTU via terminal connections and Ethernet for advanced network integration, allowing for remote monitoring and control. Commissioning typically involves setting motor parameters, defining speed references, and configuring I/O functions using the drive's intuitive menu system or via Schneider Electric's SoMove software for simplified parameterization and diagnostics.

Operation and Risk Mitigation

Safe operation of the ATV630U30N4 is paramount, and it incorporates multiple safety features, including Safe Torque Off (STO) functionality, which prevents unexpected machine startup. Proper installation, including adequate ventilation and adherence to wiring guidelines, is critical to prevent overheating and ensure long-term reliability. Common troubleshooting involves checking for error codes displayed on the drive's interface; for instance, "F0001" often indicates an overcurrent fault, requiring an investigation into motor load or acceleration ramps. Understanding these fault codes and their corresponding remedies, detailed in the product's technical documentation, is essential for minimizing downtime and ensuring the safe, continuous operation of automated production lines.

Scalability & Long-Term Value

The ATV630 series, including the ATV630U30N4, offers significant scalability and long-term value through its compatibility with Schneider Electric's EcoStruxure™ platform. This integration enables advanced data analytics, predictive maintenance, and remote asset management, aligning with Industry 4.0 principles. The drive's modular design and compatibility with a wide range of automation components facilitate easy upgrades and system expansion as production needs evolve. Its embedded intelligence and energy management features contribute to reduced operational costs over the product's lifecycle, making it a strategic investment for businesses seeking to enhance efficiency and competitiveness in their automated manufacturing processes.

Frequently Asked Questions

What are the primary advantages of using the Schneider ATV630U30N4?

The ATV630U30N4 offers superior energy efficiency through precise speed control, significantly reducing operational costs. Its advanced sensorless flux vector control ensures excellent motor performance and accuracy for demanding applications. The drive also incorporates integrated safety functions like Safe Torque Off (STO) for enhanced workplace safety.

What industrial applications are best suited for the ATV630U30N4?

This inverter is ideal for variable torque applications such as pumps and fans in HVAC or water management. It's also highly effective for material handling systems, conveyors, and precise speed control in packaging machinery. Process industries benefit from its reliable performance in food/beverage and chemical production environments.

How does the ATV630U30N4 integrate with automation systems?

It seamlessly integrates via Modbus RTU or Ethernet, enabling remote monitoring and control within SCADA or PLC systems. The drive is compatible with Schneider Electric's EcoStruxure platform for advanced IIoT capabilities and predictive maintenance. SoMove software simplifies commissioning and parameter management.

What are the power and current ratings of the ATV630U30N4?

The ATV630U30N4 is rated for a 3kW (4 HP) motor with a nominal output current of 5.8 Amperes. It operates on a 380-415V AC supply, making it suitable for standard industrial power grids in many regions. This ensures it can handle moderately sized industrial motors effectively.

Does the ATV630U30N4 support advanced motor control methods?

Yes, it features advanced sensorless flux vector control, providing high-performance torque and speed regulation without a motor encoder. This technology is crucial for applications demanding precise control and quick response to load changes. It optimizes motor performance across a wide speed range.

What is the enclosure protection rating of the ATV630U30N4?

The ATV630U30N4 comes with an IP21 enclosure rating. This means it offers protection against solid objects greater than 12.5mm and against vertically falling water droplets. It's suitable for clean, dry indoor industrial environments where splashing is not a primary concern.

What communication protocols does the ATV630U30N4 support?

The drive supports Modbus RTU over serial communication for direct connection to PLCs and HMIs. It also offers Ethernet connectivity for integration into modern industrial networks, facilitating remote diagnostics and data exchange. These protocols ensure flexible system integration.

How can I ensure safe operation with the ATV630U30N4?

Always follow the installation and wiring guidelines in the manual to prevent electrical hazards. Utilize the integrated Safe Torque Off (STO) function for emergency stops, preventing unexpected motor startup. Proper grounding and enclosure ventilation are also critical safety measures.

What are common troubleshooting steps for ATV630U30N4 faults?

Check the drive's display for specific fault codes like F0001 (overcurrent) or F0002 (overvoltage). Consult the manual to understand the cause and recommended actions, which may involve adjusting motor parameters, checking load, or verifying supply voltage. Regular maintenance also prevents many issues.

What is the scalability of the ATV630U30N4 within a larger automation system?

The ATV630U30N4 is designed for scalability, fitting into larger Schneider Electric automation architectures and the EcoStruxure ecosystem. This allows for future expansion and integration with digital solutions for enhanced plant management and optimization. Its flexible I/O and communication options support system growth.
