Siemens 3RW5147-1XC14 SIRIUS Extra High Power Soft Starter 470A 250kW

The Siemens 3RW5147-1XC14 SIRIUS Extra High Power Soft Starter is engineered to deliver superior motor control for demanding industrial applications. This advanced soft starter provides smooth acceleration, reduced mechanical stress, and enhanced energy efficiency, making it an indispensable component for optimizing operations. Key advantages include its integrated bypass for reduced energy consumption during steady-state operation and its sophisticated motor protection features, ensuring longevity and reliability. Technical parameters highlight its robust design, with a rated operational current of 470A and a maximum motor power rating of 250kW at 400V, underscoring its capability to handle substantial loads.

Siemens 3RW5147-1XC14 SIRIUS: Product Specifications

| Feature                   | Specification                                  |

| :------------------------ | :--------------------------------------------- |

| Product Type              | Soft Starter                                   |

| Series                    | SIRIUS 3RW5 Extra High Power                   |

| Model Number              | 3RW5147-1XC14                                  |

| Rated Operational Current | 470 A                                          |

| Max Motor Power (400V)    | 250 kW                                         |

| Supply Voltage Range      | 200-480 V AC                                   |

| Control Voltage           | 24 V AC/DC                                     |

| Communication Interface   | Modbus RTU, PROFIBUS DP, PROFINET (optional) |

| Protection Functions      | Motor overload, short circuit, earth fault, phase imbalance |

| Ambient Temperature       | -25 to +60 °C                                  |

| Enclosure Rating          | IP20                                           |

Core Features & Market Positioning

The Siemens 3RW5147-1XC14 stands out in the market due to its exceptionally high power density and integrated bypass functionality, which significantly reduces energy losses during continuous operation, translating into substantial cost savings and improved operational efficiency. This advanced design minimizes heat generation, allowing for more compact control cabinet installations. Its sophisticated motor protection algorithms go beyond basic overload protection, offering comprehensive safeguarding against phase failures, unbalance, and ground faults, thereby extending motor lifespan and preventing costly downtime. The SIRIUS 3RW5 series is positioned as a premium solution for applications where reliability, performance, and energy efficiency are paramount.

Key Application Scenarios

This extra-high power soft starter is ideally suited for a wide array of heavy-duty industrial applications where smooth starting and stopping of large electric motors are critical. Common scenarios include the direct control of pumps in water treatment plants and oil and gas facilities, where sudden starts can cause significant pressure surges or damage to the system. It is also extensively used in conveyor systems within the mining and material handling sectors, ensuring gradual acceleration to prevent load slippage and mechanical shock. Furthermore, its application extends to large fan and blower systems in HVAC and power generation, where reduced inrush current minimizes grid impact and noise pollution.

Practical System Integration Guidance

Integrating the Siemens 3RW5147-1XC14 into existing industrial control systems is streamlined through its flexible communication options and clear terminal layouts. For optimal performance, ensure the soft starter is installed in a well-ventilated environment, adhering to the specified ambient temperature range of -25 to +60 °C. The unit requires a 24 V AC/DC control voltage supply for its internal logic. Wiring should be performed according to local electrical codes and the manufacturer's detailed wiring diagrams, paying close attention to the correct connection of motor power terminals (L1, L2, L3), control supply, and any optional communication modules. For systems utilizing PROFIBUS or PROFINET, proper network configuration and addressing are essential for seamless data exchange and remote diagnostics.

Operation and Risk Mitigation

Operating the Siemens 3RW5147-1XC14 involves setting the appropriate motor parameters, such as rated current and trip class, via its intuitive interface or through integrated communication protocols. The soft starter's self-monitoring capabilities detect potential issues, triggering fault codes that aid in rapid troubleshooting. Critical fault codes, such as "Overload" (F01) or "Phase Failure" (F05), should be addressed immediately by investigating the motor load, power supply, and external protection devices. Risk mitigation is enhanced by the integrated bypass, which eliminates the need for external bypass contactors in many applications, simplifying the control panel and reducing potential points of failure. Always ensure the power supply is de-energized before performing any maintenance or wiring adjustments.

Scalability & Long-Term Value

The Siemens 3RW5147-1XC14 offers significant long-term value through its compatibility with the broader Siemens SIRIUS ecosystem and its inherent scalability. It seamlessly integrates with other SIRIUS devices, such as circuit breakers and contactors, enabling a cohesive and standardized control solution. For facilities embracing Industry 4.0 principles, the optional communication modules (PROFIBUS DP, PROFINET) allow for real-time monitoring, diagnostics, and control within industrial IoT platforms, providing valuable data for predictive maintenance and process optimization. This forward-looking design ensures that the soft starter can adapt to evolving plant requirements and digital transformation initiatives, safeguarding the investment over the long term.

Frequently Asked Questions

What is the primary function of the Siemens 3RW5147-1XC14?

It smoothly starts electric motors, reducing mechanical stress and inrush current. This protects equipment and the power grid.

It prevents damage from hard starts and minimizes wear on motor components. This extends the operational life of connected machinery.

The integrated bypass conserves energy when the motor runs at full speed. This leads to operational cost savings.

How does the Siemens 3RW5147-1XC14 handle motor protection?

It offers comprehensive protection against common motor faults. This includes overload, short-circuit, and earth faults.

It also protects against phase imbalances and phase failures. This ensures the motor operates within safe parameters.

These advanced features help prevent premature motor failure and reduce unscheduled downtime.

What is the power rating of the Siemens 3RW5147-1XC14?

This soft starter can handle a maximum motor power of 250kW at 400V. Its rated operational current is 470A.

This specification indicates its suitability for large industrial motors and demanding applications.

It is designed for extra high power requirements in various industrial settings.

What are the advantages of the integrated bypass in this soft starter?

The bypass significantly reduces energy consumption during steady-state operation. This leads to lower electricity bills.

It also minimizes heat generation within the soft starter itself. This allows for more compact control panel designs.

The integrated bypass simplifies wiring and reduces the need for external components.

What communication protocols does the Siemens 3RW5147-1XC14 support?

It natively supports Modbus RTU for basic communication. This allows for straightforward integration with many control systems.

Optional modules enable support for PROFIBUS DP and PROFINET. These industrial Ethernet protocols offer advanced diagnostics and integration capabilities.

These communication options facilitate remote monitoring, control, and seamless integration into automated systems.

What is the typical application for a 470A soft starter?

Applications include starting large pumps in water or oil industries. It's also used for heavy-duty conveyor belts in mining.

Large fan and blower systems in power generation or industrial ventilation use this starter. Its high current rating suits these loads.

It's ideal for any situation requiring controlled acceleration of high-power electric motors.

How do I install the Siemens 3RW5147-1XC14?

Mount the unit in a well-ventilated area, respecting ambient temperature limits. Ensure proper clearance for heat dissipation.

Wire the motor power terminals and control supply according to the manual and local codes. Use appropriate cable sizes for 470A.

Set the motor parameters and commissioning the device either via keypad or communication interface.

What happens if the Siemens 3RW5147-1XC14 detects a fault?

The soft starter will display a specific fault code on its HMI. This indicates the nature of the problem, such as overload or phase loss.

It will typically shut down the motor to prevent damage. This is a safety feature to protect both the motor and the system.

Troubleshooting involves consulting the manual for the specific fault code meaning and taking corrective action.

Can this soft starter be used with existing Siemens control systems?

Yes, it is part of the SIRIUS modular system, ensuring compatibility. It integrates well with other SIRIUS components like contactors.

With optional communication modules, it easily connects to PROFINET or PROFIBUS networks. This allows integration into Siemens PLC systems.

This ensures a cohesive and standardized approach to motor control within a Siemens automation architecture.

What is the long-term value of using this specific soft starter model?

Its robust design and comprehensive protection extend motor life. This reduces maintenance costs and downtime.

The integrated bypass and efficient operation lead to energy savings over time. This improves the overall economic efficiency of the plant.

Its compatibility with digital communication protocols future-proofs the investment for IIoT integration.
