Yaskawa SGMXJ-08AUA6SC2 Industrial Automation Brake Servo Motor

The Yaskawa SGMXJ-08AUA6SC2 is a high-performance industrial automation brake servo motor engineered for demanding applications requiring precision, reliability, and robust control. This motor distinguishes itself through its integrated brake system, offering enhanced safety and holding torque capabilities, crucial for vertical axis applications and emergency stops. Its core advantages lie in its superior positional accuracy, rapid response times, and compatibility with Yaskawa's advanced servo drives, enabling seamless integration into complex automation systems.

Product Specifications

| Parameter            | Value                 |

| :------------------- | :-------------------- |

| Model Number         | SGMXJ-08AUA6SC2       |

| Rated Voltage        | 200V Class            |

| Output Power         | 750W (1HP)            |

| Rated Torque         | 2.39 Nm               |

| Peak Torque          | 7.17 Nm               |

| Rated Speed          | 3000 r/min            |

| Encoder Resolution   | 20-bit absolute encoder |

| Brake Type           | Holding Brake         |

| Frame Size           | 80mm                  |

| Protection Class     | IP65                  |

Core Features & Market Positioning

The Yaskawa SGMXJ-08AUA6SC2 stands out in the industrial automation market due to its robust construction and advanced features designed for mission-critical operations. The integrated holding brake provides instant and secure stopping power, significantly reducing settling time and enhancing safety in applications involving vertical loads or potential power loss. This motor leverages Yaskawa's renowned Sigma-7 technology, ensuring high precision and smooth operation even under dynamic conditions. Its market positioning is firmly within high-end automation, where reliability, precise motion control, and operational safety are paramount, making it a preferred choice for sophisticated manufacturing and robotics.

Key Application Scenarios

This servo motor is ideally suited for a variety of demanding industrial applications. Its robust braking system makes it particularly effective in robotics, especially for articulated arms requiring precise positioning and secure holding. It is also a prime candidate for material handling equipment, including vertical lifts and conveyors, where maintaining position during operation or power interruption is critical. Furthermore, the SGMXJ-08AUA6SC2 excels in packaging machinery, assembly lines, and CNC machines where high accuracy, rapid acceleration/deceleration, and reliable stopping are essential for product quality and throughput.

Practical System Integration Guidance

Integrating the Yaskawa SGMXJ-08AUA6SC2 into an automation system is streamlined through compatibility with Yaskawa's Sigma-7 servo drives, such as the SGD7S series. Proper wiring is essential; ensure the power and encoder cables are correctly connected to the designated terminals on the servo drive to avoid communication errors or damage. For commissioning, utilize the Yaskawa Sigma-WIN+ software for motor setup, parameter configuration, and tuning. This software allows for precise adjustment of gain settings, inertia compensation, and load control, ensuring optimal performance tailored to the specific application. Establishing safe operating zones and emergency stop protocols within the machine's controller is also a vital step in system integration.

Operation and Risk Mitigation

Safe operation of the Yaskawa SGMXJ-08AUA6SC2 hinges on adhering to operational parameters and implementing robust safety measures. Always ensure the motor is correctly installed and grounded to prevent electrical hazards. The integrated brake should be regularly inspected for wear and proper functionality, especially in applications with frequent stopping cycles. Refer to the service manual for specific maintenance schedules. Common troubleshooting may involve checking encoder feedback signals, servo drive status lights, and alarm codes displayed on the drive or HMI. For instance, an "over-current" alarm might indicate a mechanical binding issue or an incorrect gain setting, while an "encoder error" could point to a loose connection or damaged cable.

Scalability & Long-Term Value

The Yaskawa SGMXJ-08AUA6SC2 offers significant scalability and long-term value within an industrial automation framework. Its compatibility with the broader Yaskawa Sigma-7 ecosystem allows for easy integration with multiple servo drives and controllers, facilitating expansion of automated systems. This motor can be readily incorporated into existing Yaskawa-based platforms or upgraded as part of a comprehensive automation modernization project. Furthermore, its adherence to industry standards and Yaskawa's commitment to backward compatibility ensure that systems built around this motor can evolve with technological advancements, including integration with IIoT platforms and advanced analytics for predictive maintenance and performance optimization.
